Brother MFC-9010CN Service Manual

1-28
Confidential
The table below shows the printable areas when printing on Landscape for each paper size.
Specifications are subject to change without notice.
Size ABCDEH
Letter
(mm)
(inch)
(dots)
279.4
11
3,300
215.9
8.5
2,550
270.9
10.67
3,200
207.4
8.17
2,450
4.23
0.17
50
4.23
0.17
50
Legal
(mm)
(inch)
(dots)
355.6
14
4,200
215.9
8.5
2,550
347.1
13.67
4,100
207.4
8.17
2,450
4.23
0.17
50
4.23
0.17
50
Folio
(mm)
(inch)
(dots)
330.2
13
3,900
215.9
8.5
2,550
321.7
12.67
3,800
207.4
8.17
2,450
4.23
0.17
50
4.23
0.17
50
Executive
(mm)
(inch)
(dots)
266.7
10.5
3,150
184.2
7.25
2,175
258.2
10.17
3,050
175.7
6.92
2,075
4.23
0.17
50
4.23
0.17
50
A4
(mm)
(inch)
(dots)
297
11.7
3,507
210
8.3
2,480
288
11.4
3,407
202
7.9
2,380
4.23
0.17
50
4.23
0.17
50
A5
(mm)
(inch)
(dots)
210
8.3
2,480
148
5.8
1,748
202
7.9
2,380
140
5.5
1,648
4.23
0.17
50
4.23
0.17
50
A5 Long Edge
(mm)
(inch)
(dots)
148
5.8
1,748
210
8.3
2,480
140
5.5
1,648
202
7.9
2,380
4.23
0.17
50
4.23
0.17
50
A6
(mm)
(inch)
(dots)
148
5.8
1,748
105
4.1
1,240
140
5.5
1,648
97
3.8
1,140
4.23
0.17
50
4.23
0.17
50
B5 (JIS)
(mm)
(inch)
(dots)
257
10.1
3,030
182
7.2
2,148
248
9.8
2,930
173
6.8
2,048
4.23
0.17
50
4.23
0.17
50
B5 (ISO)
(mm)
(inch)
(dots)
250
9.8
2,952
176
6.9
2,078
241
9.5
2,852
167
6.6
1,978
4.23
0.17
50
4.23
0.17
50
B6 (JIS)
(mm)
(inch)
(dots)
182
7.2
2,149
128
5
1,511
173
6.8
2,049
119
4.7
1,411
4.23
0.17
50
4.23
0.17
50
B6 (ISO)
(mm)
(inch)
(dots)
176
6.9
2,078
125
4.9
1,476
167
6.6
1,978
117
4.6
1,376
4.23
0.17
50
4.23
0.17
50
Envelope
Monarch
(mm)
(inch)
(dots)
190.5
7.5
2,250
98.4
3.875
1,162
182
7.17
2,150
89.9
3.54
1,062
4.23
0.17
50
4.23
0.17
50
Envelope
Com-10
(mm)
(inch)
(dots)
241.3
9.5
2,850
104.7
4,125
1,237
232.8
9.17
2,750
96.3
3.79
1,137
4.23
0.17
50
4.23
0.17
50
Envelope DL
(mm)
(inch)
(dots)
220
8.7
2,598
110
4.3
1,299
211
8.3
2,498
102
4
1,199
4.23
0.17
50
4.23
0.17
50
Envelope C5
(mm)
(inch)
(dots)
229
9
2,704
162
6.4
1,913
220
8.7
2,604
154
6
1,813
4.23
0.17
50
4.23
0.17
50
Hagaki
(mm)
(inch)
(dots)
148
5.8
1,748
100
3.9
1,181
140
5.5
1,648
92
3.6
1,081
4.23
0.17
50
4.23
0.17
50
A4 Long
(mm)
(inch)
(dots)
405
15.9
4,783
210
8.3
2,480
396
15.6
4,683
202
7.9
2,380
4.23
0.17
50
4.23
0.17
50
DL Long
Edge
(mm)
(inch)
(dots)
110
4.3
1,299
220
8.7
2,598
102
4
1,199
207
8.2
2,450
4.23
0.17
50
6.27
0.25
74
3X5
(mm)
(inch)
(dots)
127
5
1,500
76.2
3
900
118.5
4.67
1,400
67.7
2.67
800
4.23
0.17
50
4.23
0.17
50
Note:
- The paper sizes indicated here should confirm to the nominal dimensions specified by JIS
except B5 (ISO), B6 (ISO).
- The dot size is based on 300 dpi resolution.
