Paper size according to the printer driver settings.
This size is not necessarily matched with the actual paper size.
*4
01 to 10 are entered in ## in chronological order
.
When you press the
OK
button as the
machine error history is displayed, the page counter values when the errors occurred are
displayed
.
When you press the
OK
button again, the machine error history is displayed again.
*5
01 to 03 are entered in ## in chronological order. When you press the
OK
button as the
communication error history is displayed, the page counter values when the errors occurred are
displayed. When you press the
OK
button again, the machine error history is displayed again.
*6
01 to 10 are entered in ## in chronological order. When you press the OK button as the
engine error history is displayed, TM: elapsed time (minute) from the previous error and BT:
the number of times when the power is ON are displayed. When you press the OK button
again, the engine error history is displayed again.
LCD Description
Print pages
by paper
type
*3
PLTNRE: Printed pages of plain, thin, and recycled paper
TKTRBD: Printed pages of thick, thicker, and bond paper
ENVTYP: Printed pages of envelope, envelope thick, and
envelope thin
HAGAKI: Printed pages of Hagaki
LABEL: Printed pages of label
ADSX_PG Number of single-sided scanned pages with the ADF
FB_PG Number of scanned pages with the FB unit
Developing
bias related
items
CDEV_BIAS: Cyan developing bias voltage (unit: V)
MDEV_BIAS: Magenta developing bias voltage (unit: V)
YDEV_BIAS: Yellow developing bias voltage (unit: V)
KDEV_BIAS: Black developing bias voltage (unit: V)
Power
distribution
time
POWER: Power distribution time
PWRCNT: Number of times that the power is turned ON
Jam related
items
TTL_JAM: Total number of jams
TR1_JAM: Number of jams that occurred at the paper tray
IN_JAM: Number of jams that occurred inside the machine
RE_JAM: Number of jams that occurred at the ejecting
ADSX_JAM: Number of jams that occurred at singled sided
scanning with the ADF
Number of
error
occurrences
HODN_ER: Number of discharge errors due to smear of the
corona wire
FUSR_ER: Number of times that fuser unit error occurs
MTLK_ER: Number of times that motor lock error occurs
(Not used)
Error log
related
items
MACHINEERR_##:
*4
Machine error ##: Error code/number of occurrences
COMERR##:
*5
Last communication error code
ENGERR##:
*6
Engine error ##: Error level (2 bytes),
large classification code (2 bytes),
detailed classification code (2 bytes)
