App.1-32
Confidential
■ WSW36 (Function setting 14)
*ECP (Enhanced Capabilities Port)
- Selector 5: Escape from phase C
This selector determines whether or not the machine will escape from phase C when it detects an
RTC (Return to Control) in non-ECM mode or an RCP (Return to Control Partial page) in ECM
mode.
- Selectors 6 through 8: Extension of incoming calling signal (CI) frequency band
specified by selectors 1 through 4 on WSW14
At the start of reception, if the machine detects the frequency of a CI signal specified by selectors 1
through 4 on WSW14, it starts the ringer sounding. However, the machine may fail to detect the CI
signal normally due to noise superimposed at the time of reception. To prevent it, use selectors 6
through 8 on WSW36.
If the machine detects higher frequencies than the setting made here, it regards them as noise and
interprets the detecting state as being normal, allowing the ringer to keep sounding according to the
preset number of ringers (until it starts automatic reception of FAX data in the FAX mode or enters
the TAD mode in the TEL mode).
Selector No. Function Setting and Specifications
1 ECP mode* (Not used.)
2
Recovery from Inactive PC Interface
(Not used.)
3
PC Power-off Recognition Time
(Not used.)
4 Not used.
5 Escape from phase C
0: Yes
1: No
6
l
8
Extension of incoming calling signal
(CI) frequency band specified by
selectors 1 through 4 on WSW14
No. 6 7 8
0 0 0: 0
0 0 1: 4
0 1 0: 8
0 1 1: 12
1 0 0: 16
1 0 1: 20
1 1 0: 24
1 1 1: 28
(Ignored)
(448 Hz)
(244 Hz)
(162 Hz)
(122 Hz)
(97 Hz)
(81 Hz)
(69 Hz)
Note:
Selectors 2 and 3 will become operative if selectors 1 and 2 of WSW46 are set to “monitor” the
PC power ON/OFF state.
