Brother MFC-9010CN Service Manual

App.1-44
Confidential
■ WSW54 (Function setting 20)
- Selector 3: More CNG detection cycles in user-friendly reception
If CNG detection fails even after adjustment of selectors 4 and 5 on WSW26, try adding 2 more
cycles to the permitted number of CNG detection cycles.
- Selectors 5 and 6: Caller ID tone alert detection time length
In the event of a false detection of a caller ID tone alert, adjust the detection time length.
- Selector 7: Caller ID mild pulse transmission
If a caller ID (number display) cannot be displayed due to mild pulses transmitted after detection of
tone alert, use this selector so as to make it impossible to transmit mild pulses.
- Selector 8: Switching between DTMF and FSK for caller ID reception (China only)
If a caller ID (number display) cannot be received, switch from DTMF to FSK. This operation can
also be performed by means of the menu, by switching between DTMF and FSK.
Selector No. Function Setting and Specifications
1
2
PictBridge command delay time
No. 1 2
0 0: 100 ms (default)
0 1: 0 ms
1 0: 50 ms
1 1: 200 ms
3
More CNG detection cycles in
user-friendly reception
0: No
1: 2 more cycles
4
Cordless handset ID recovery future
(Not used.)
5
6
Caller ID tone alert detection time
length (U.K. only)
No. 5 6
0 0: 10 ms (default)
0 1: 20 ms
1 0: 30 ms
1 1: 40 ms
7
Caller ID wet pulse transmission
(U.K. only)
0: Yes (default)
1: No
8
Switching between DTMF and FSK
for caller ID reception (China only)
0: DTMF (default)
1: FSK
Note:
- Selectors 5 through 7 are applicable only to models designed for the UK market.
- Selector 8 is applicable only to models designed for the Chinese market.
