Brother MFC-9010CN Service Manual

App.1-46
Confidential
■ WSW57 (Function setting 22)
■ WSW58 (Function setting 23)
Selector No. Function Setting and Specifications
1
l
3
Caller ID judgment voltage (to be
distinguished from rings) (Not used.)
4
l
6
Caller ID judgment voltage (to be
distinguished from reverse polarity
voltages) (Not used.)
7 Caller ID burst link time limit
0: Enable
1: Disable
8
Base unit Start button after cordless
handset dialing (Not used.)
Selector No. Function Setting and Specifications
1
l
3
Prevention of line interrupt during
ICM recording (ratio of guard tone
response time to call end tone ON
time) (Not used.)
4
5
Not used.
6
Extension of the “No. of CNG cycles
to be detected” (which allows two
cycles to be added to the cycles
specified by selectors 6 and 7 on
WSW26 and selectors 4 and 5 on
WSW34) (Not used.)
7
8
No. of busy tone detection cycles
(Not used.)
