2-4
Confidential
â–  ADF part
Fig. 2-4
Separation roller shaft ASSY
Pressure roller
Pressure roller
Document rear actuator
Document front actuator
Pressure roller
Ejection roller
Separation pad
Separation roller
CIS unit
Document rear sensor
Document front sensor
Timing belt
ADF cover open sensor
Pulley ASSY
<Right side><Left side>
Suction roller
Paper feed roller
