Brother MFC-9010CN Service Manual

2-32
Confidential
■ Location of sensors
Fig. 2-30
Fig. 2-31
<Front>
Eject gear cover
Registration sensor
Waste toner
Registration rear sensor
Registration front sensor
Fuser/eject
Waste toner sensor
Paper feed unit
Manual sensor
Registration front/rear
sensor PCB ASSY
sensor holder
Registration mark sensor L
drive motor
sensor
Density sensor
Belt thermistor
Registration mark sensor R
holder ASSY
Paper eject guide ASSY
Paper eject rear sensor
Toner LED
Develop release
New toner sensor
Drum motor
Paper eject front
<Front>
Toner sensor
Internal temperature
origin sensor
sensor
Top cover open
switch
Back cover sensor
External temperature/
humidity sensor
(Light emission)
(Light reception)
sensor (Fuser cover)
sensor
