Programming Guide | VLT® AutomationDrive FC 360
Setup: All setups Conversion index: 0
Data type: Uint32 Change during operation: True
This parameter holds the state of the bus-controlled digital outputs and relays. A logical 1 indicates that the output is high or active. A
logical 0 indicates that the output is low or inactive.
Table 18: Bit Functions
Bit 0 Digital output terminal 27
Bit 1 Digital output terminal 29
Bit 2–3 Reserved
Bit 4 Relay 1 output terminal
Bit 6–23 Reserved
Bit 24 Terminal 42 digital output
Bit 26–31 Reserved
5-93 Pulse Out 27 Bus Control
Default value: 0.00% Parameter type: Range (0.00–100.00%)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Set the output frequency transferred to the output terminal 27 when the terminal is configured as [45] Bus Controlled in parameter 5-60
Terminal 27 Pulse Output Variable.
5-94 Pulse Out 27 Timeout Preset
Default value: 0.00% Parameter type: Range (0.00–100.00%)
Setup: 1 setup Conversion index: -2
Data type: Uint16 Change during operation: True
Set the output frequency transferred to the output terminal 27 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-60 Terminal 27 Pulse Output Variable and a timeout is detected.
5-95 Pulse Out 29 Bus Control
Default value: 0.00% Parameter type: Range (0.00–100.00%)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Set the output frequency transferred to the output terminal 29 when the terminal is configured as [45] Bus Controlled in parameter 5-63
Terminal 29 Pulse Output Variable.
5-96 Pulse Out 29 Timeout Preset
Default value: 0.00% Parameter type: Range (0.00–100.00%)
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 143
