Programming Guide | VLT® AutomationDrive FC 360
Option Name
[121] 440-480V/60Hz/Delta
[122] 440-480V/60Hz
0-07 Auto DC Braking
Default value: [1] On Parameter type: Option
Setup: 1 setup Conversion index: –
Data type: Uint8 Change during operation: False
Protective function against overvoltage at coast in IT grid environment. This parameter is active only when [1] On is selected in this
parameter.
Option Name Description
[0] Off This function is not active.
[1] On This function is active.
4.1.3 0-1* Set-up Operations
Define and control the individual parameter setups. The drive has 2 parameter setups that can be programmed independently of
each other. This makes the drive flexible and able to solve advanced control functionality problems, often saving the cost of external
control equipment. For example, the 2 setups can be used to program the drive to operate according to 1 control scheme in 1 setup (for
example, motor 1 for horizontal movement) and another control scheme in another setup (for example, motor 2 for vertical movement).
Alternatively, they can be used by an OEM machine builder to program all their factory-fitted drives for different machine types within
a range to have the same parameters and then during production/commissioning simply select a specific setup, depending on which
machine the drive is installed on.
The active setup (that is, the setup in which the drive is operating) can be selected in parameter 0-10 Active Set-up and is shown in the
LCP. By selecting [9] Multi Set-up, it is possible to switch between setups with the drive running or stopped, via digital input or serial
communication commands. If it is necessary to change setups while running, ensure that parameter 0-12 Link Setups is set as required.
Use parameter 0-11 Programming Set-up to edit parameters within any of the setups while continuing the operation of the drive in its
active setup, which can be a different setup to that being edited. Use parameter 0-51 Set-up Copy to copy parameter settings between
the setups to enable quicker commissioning if similar parameter settings are required in different setups.
0-10 Active Set-up
Default value: [1] Set-up 1 Parameter type: Option
Setup: 1 setup Conversion index: –
Data type: Uint8 Change during operation: True
Select the setup in which the drive is to operate. Select parameter 0-51 Set-up Copy to copy a setup to 1 or all setups. To avoid conflicting
settings of the same parameter within 2 different setups, link the setups together in parameter 0-12 Link Setups. Stop the drive before
switching between setups where the parameters are marked Not changeable during operation. Parameters which are Not changeable
during operation are marked False.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 35
