Programming Guide | VLT® AutomationDrive FC 360
16-79 Analog output 45 [mA]
Default value: 0.00 mA Parameter type: Range (0.00–20.00 mA)
Setup: 1 setup Conversion index: -2
Data type: Uint16 Change during operation: True
View the actual value at output 45 in mA. The value shown reflects the selection in parameter 6-70 Terminal 45 Mode and parameter
6-71 Terminal 45 Analog Output.
4.15.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control words.
16-80 Fieldbus CTW 1
Default value: 0 Parameter type: Range (0–65535)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
View the 2 byte control word (CTW) received from the bus master. Interpretation of the CTW depends on the fieldbus option installed
and the CTW profile selected in parameter 8-10 Control Word Profile. For more information, refer to the relevant fieldbus manuals.
16-82 Fieldbus REF 1
Default value: 0 Parameter type: Range (-32768–32767)
Setup: 1 setup Conversion index: 0
Data type: Int16 Change during operation: True
To set the reference value, view the 2 byte word sent with the control word from the bus master. For more information, refer to the
relevant fieldbus manual.
16-84 Comm. Option STW
Default value: 0 Parameter type: Range (0–65535)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
View the extended fieldbus communication option status word. For more information, refer to the relevant fieldbus manual.
16-85 FC Port CTW 1
Default value: 1084 Parameter type: Range (0–65535)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: False
View the 2 byte control word (CTW) received from the bus master. Interpretation of the control word depends on the fieldbus option
installed and the control word profile selected in parameter 8-10 Control Word Profile.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 263
