Data type: Int32 Change during operation: False
View the actual value of impulses applied to terminal 27 in digital output mode.
16-70 Pulse output 29 [Hz]
Default value: 0 Parameter type: Range (0–40000)
Setup: All setups Conversion index: 0
Data type: Int32 Change during operation: False
View the actual value of pulses to terminal 29 in digital output mode.
16-71 Relay output
Default value: 0 Parameter type: Range (0–31)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
View the settings of all relays.
Table 23: Bits Definition
Bits Definition
Bit 3 User relay 02
Bit 4 User relay 01
16-72 Counter A
Default value: 0 Parameter type: Range (-32768–32767)
Setup: 1 setup Conversion index: 0
Data type: Int16 Change during operation: True
View the present value of counter A. Counters are useful as comparator operands, see parameter 13-10 Comparator Operand. The value
can be reset or changed either via digital inputs (parameter group 5-1* Digital Inputs) or by using an SLC action (parameter 13-52 SL
Controller Action).
16-73 Counter B
Default value: 0 Parameter type: Range (-32768–32767)
Setup: 1 setup Conversion index: 0
Data type: Int16 Change during operation: True
View the present value of counter B. Counters are useful as comparator operands, see parameter 13-10 Comparator Operand. The value
can be reset or changed either via digital inputs (parameter group 5-1* Digital Inputs) or by using an SLC action (parameter 13-52 SL
Controller Action).
