Programming Guide | VLT® AutomationDrive FC 360
View the actual value at input 54.
16-65 Analog output 42 [mA]
Default value: 0.00 mA Parameter type: Range (0.00–20.00 mA)
Setup: 1 setup Conversion index: -2
Data type: Uint16 Change during operation: True
View the actual value at output 42. The value shown reflects the selections in parameter 6-90 Terminal 42 Mode and parameter 6-91
Terminal 42 Analog Output.
16-66 Digital Output
Default value: 0 Parameter type: Range (0–63)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
View the binary value of all digital outputs.
Table 22: Bits Definition
Bits Definition
Bit 2 Digital input terminal 29
Bit 3 Digital input terminal 27
Bit 4 Digital input terminal 45
Bit 5 Digital input terminal 42
16-67 Pulse input 29 [Hz]
Default value: 0 Parameter type: Range (0–130000)
Setup: All setups Conversion index: 0
Data type: Int32 Change during operation: False
View the actual frequency rate on terminal 29.
16-68 Pulse input 33 [Hz]
Default value: 0 Parameter type: Range (0–130000)
Setup: All setups Conversion index: 0
Data type: Int32 Change during operation: False
View the actual value of the frequency applied at terminal 33 as an impulse input.
16-69 Pulse output 27 [Hz]
Default value: 0 Parameter type: Range (0–40000)
Setup: All setups Conversion index: 0
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 261
