Danfoss VLT AutomationDrive FC 360 Programming Guide

4.16.4 17-5* Resolver Interface
 NOTICE
This parameter group is only valid when VLT® Resolver Option MCB 103 is installed.
17-50 Poles
Default value: 2 Parameter type: Range (2–2)
Setup: 1 setup Conversion index: 0
Data type: Uint8 Change during operation: False
Set the pole numbers for the resolver.
17-51 Input Voltage
Default value: 7.0 V Parameter type: Range (2.0–8.0 V)
Setup: 1 setup Conversion index: -1
Data type: Uint8 Change during operation: False
Set the input voltage for the resolver.
17-52 Input Frequency
Default value: 10.0 kHz Parameter type: Range (2.0–15.0 kHz)
Setup: 1 setup Conversion index: -1
Data type: Uint8 Change during operation: False
Set the input frequency for the resolver.
17-53 Transformation Ratio
Default value: 0.5 Parameter type: Range (0.1–1.1)
Setup: 1 setup Conversion index: -1
Data type: Uint8 Change during operation: False
Set the transformation ratio for the resolver.
17-56 Encoder Sim. Resolution
Default value: [0] Disabled Parameter type: Option
Setup: 1 setup Conversion index: –
Data type: Uint8 Change during operation: False
Set the encoder simulation resolution.
268 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
