Programming Guide | VLT® AutomationDrive FC 360
17-21 Resolution (Positions/Rev)
Default value: Size related Parameter type: Range (4–1073741824)
Setup: All setups Conversion index: 0
Data type: Uint32 Change during operation: False
Select the resolution of the absolute encoder, that is, the number of counts per revolution.
17-22 Multiturn Revolutions
Default value: 1 Parameter type: Range (1–16777216)
Setup: All setups Conversion index: 0
Data type: Uint32 Change during operation: False
Set the number of multi-turn revolutions. Selecting '1' means that the encoder is a single-turn type.
17-24 SSI Data Length
Default value: 13 Parameter type: Range (1–32)
Setup: All setups Conversion index: 0
Data type: Uint8 Change during operation: False
Set number of bits for the SSI telegram.
17-25 Clock Rate
Default value: 260 kHz Parameter type: Range (100–260 kHz)
Setup: All setups Conversion index: 0
Data type: Uint16 Change during operation: False
Set the clock rate for the SSI clock. When having long cables the clock rate must be reduced.
17-26 SSI Data Format
Default value: [0] Gray code Parameter type: Option
Setup: All setups Conversion index: –
Data type: Uint8 Change during operation: False
Set the data format of the SSI data.
Option Name
[0] Gray code
[1] Binary code
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 267
