4.7.4 6-2* Analog Input 54
Parameters for configuring the scaling and limits for analog input 54 (terminal 54).
6-20 Terminal 54 Low Voltage
Default value: 0.07 V Parameter type: Range (0.00–10.00 V)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Enter the voltage (V) that corresponds to the low reference value (set in parameter 6-24 Terminal 54 Low Ref./Feedb. Value). To activate
parameter 6-01 Live Zero Timeout Function, set the value to >1 V.
6-21 Terminal 54 High Voltage
Default value: 10.00 V Parameter type: Range (0.00–10.00 V)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Enter the voltage (V) that corresponds to the high reference value (set in parameter 6-25 Terminal 54 High Ref./Feedb. Value).
6-22 Terminal 54 Low Current
Default value: 4.00 mA Parameter type: Range (0.00–20.00 mA)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Enter the low current value. This reference signal corresponds to the low reference feedback value set in parameter 6-24 Terminal 54 Low
Ref./Feedb. Value. To activate the Live Zero Timeout function in parameter 6-01 Live Zero Timeout Function, set the value to >2 mA.
6-23 Terminal 54 High Current
Default value: 20.00 mA Parameter type: Range (0.00–20.00 mA)
Setup: All setups Conversion index: -2
Data type: Uint16 Change during operation: True
Enter the high current value corresponding to the high reference feedback value set in parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
6-24 Terminal 54 Low Ref./Feedb. Value
Default value: 0.000 Parameter type: Range (-4999.000–4999.000)
Setup: All setups Conversion index: -3
Data type: Int32 Change during operation: True
Enter the reference or feedback value that corresponds to the voltage or current set in parameter 6-21 Terminal 54 High
Voltage/parameter 6-22 Terminal 54 Low Current.
