Programming Guide | VLT® AutomationDrive FC 360
16-52 Feedback[Unit]
Default value: 0.000 ProcessCtrlUnit Parameter type: Range (-4999.000–4999.000
ProcessCtrlUnit)
Setup: 1 setup Conversion index: -3
Data type: Int32 Change during operation: True
View the feedback unit calculated from the selection of unit and scaling in parameter 3-00 Reference Range, parameter 3-01 Reference/
Feedback Unit, parameter 3-02 Minimum Reference, and parameter 3-03 Maximum Reference.
16-53 Digi Pot Reference
Default value: 0.00 Parameter type: Range (-200.00–200.00)
Setup: All setups Conversion index: -2
Data type: Int16 Change during operation: False
View the contribution of the Digital Potentiometer to the actual reference.
16-57 Feedback [RPM]
Default value: 0 RPM Parameter type: Range (-30000–30000 RPM)
Setup: All setups Conversion index: 0
Data type: Int32 Change during operation: False
Readout parameter where the actual motor RPM from the feedback source can be read in both closed loop and open loop. The feedback
source is selected in parameter 7-00 Speed PID Feedback Source.
4.15.5 16-6* Inputs & Outputs
16-60 Digital Input
Default value: 0 Parameter type: Range (0–4095)
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
View the actual state of the digital inputs 18, 19, 27, and 29.
Table 21: Bits Definition
Bits Definition
Bit 0 Digital input terminal 33
Bit 1 Digital input terminal 32
Bit 2 Digital input terminal 29
Bit 3 Digital input terminal 27
Bit 4 Digital input terminal 19
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 259
