4.17.4 18-8* Compatibility
18-87 Inv. Max. Current
Default value: 0.00 A Parameter type: Range (0.00–9999.99 A)
Setup: 1 setup Conversion index: -2
Data type: Uint32 Change during operation: True
View the inverter maximum current, which should match the nameplate data on the connected motor. The data are used for calculation
of torque, motor overload protection, and so on.
18-88 Motor current
Default value: 0.00 A Parameter type: Range (0.00–9999.99 A)
Setup: 1 setup Conversion index: -2
Data type: Uint32 Change during operation: True
View the motor current measured as a mean value, IRMS. The value is filtered, and thus approximately 1.3 s may pass from when an input
value changes to when the data readout values change.
4.17.5 18-9* PID Readouts
18-90 Process PID Error
Default value: 0.0% Parameter type: Range (-200.0–200.0%)
Setup: All setups Conversion index: -1
Data type: Int16 Change during operation: False
Give the present error value used by the Process PID Controller.
18-91 Process PID Output
Default value: 0.0% Parameter type: Range (-200.0–200.0%)
Setup: All setups Conversion index: -1
Data type: Int16 Change during operation: False
Give the present raw output value from the Process PID Controller.
18-92 Process PID Clamped Output
Default value: 0.0% Parameter type: Range (-200.0–200.0%)
Setup: All setups Conversion index: -1
Data type: Int16 Change during operation: False
Give the present output value from the Process PID Controller after the clamp limits have been observed.
18-93 Process PID Gain Scaled Output
Default value: 0.0% Parameter type: Range (-200.0–200.0%)
Setup: All setups Conversion index: -1
272 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
