Setup: All setups Conversion index: –

Data type: Uint8 Change during operation: True

Select the function of Terminal 42 as an analog current output.

Option Name Range

[0] No operation

[100] Output frequency 0–100 Hz

[101] Reference Min

Ref

–Max

Ref

[102] Process Feedback Min

–Max

[103] Motor Current 0–I

max

[104] Torque rel to limit

[105] Torq relate to rated

[106] Power 0–P

nom

[107] Speed

[111] Speed Feedback

[113] PID Clamped Output

[139] Bus Control 0–100%

[143] Ext. CL 1

[254] DC Link Voltage

6-92 Terminal 42 Digital Output

Default value: [0] No operation Parameter type: Option

Setup: All setups Conversion index: –

Data type: Uint8 Change during operation: True

For the options of parameter 6-92 Terminal 42 Digital Output, see parameter 6-72 Terminal 45 Digital Output.

6-93 Terminal 42 Output Min Scale

Default value: 0.00% Parameter type: Range (0.00–200.00%)

Setup: All setups Conversion index: -2

Data type: Uint16 Change during operation: True

Scale for the minimum output (0 mA or 4 mA) of the analog signal at terminal 42. Set the value to be the percentage of the full range of

the variable selected in parameter 6-91 Terminal 42 Analog Output.

6-94 Terminal 42 Output Max Scale

Default value: 100.00% Parameter type: Range (0.00–200.00%)
