Programming Guide | VLT® AutomationDrive FC 360
12-93 Cable Error Length
Default value: 0 Parameter type: Range (0–65535), Array [2]
Setup: 1 setup Conversion index: 0
Data type: Uint16 Change during operation: True
If cable diagnostics is enabled in parameter 12-90 Cable Diagnostic, the built-in switch is possible via time domain reflectometry
(TDR). This is a measurement technique which detects common cabling problems such as open circuits, short circuits, and impedance
mismatches or breaks in transmission cables. The distance from the option to the error is shown in meters with an accuracy of ±2 m (6.6
ft). The value 0 means no errors detected.
12-94 Broadcast Storm Protection
Default value: -1% Parameter type: Range (-1%–20%)
Setup: 1 setup Conversion index: 0
Data type: Int8 Change during operation: True
The built-in switch is capable of protecting the switch system from receiving too many broadcast packages, which can use up network
resources. The value indicates a percentage of the total bandwidth that is allowed for broadcast messages.
Example:
OFF means that the filter is disabled - all broadcast messages are passed through. The value 0% means that no broadcast messages are
passed through. A value of 10% means that 10% of the total bandwidth is allowed for broadcast messages. If the number of broadcast
messages exceeds the 10% threshold, they are blocked.
12-95 Broadcast Storm Filter
Default value: [0] Broadcast only Parameter type: Option
Setup: 1 setup Conversion index: –
Data type: Uint8 Change during operation: True
Apply to parameter 12-94 Broadcast Storm Protection, if the broadcast storm protection also includes multicast telegrams.
Option Name
[0] Broadcast only
[1] Broadcast & Multicast
12-96 Port Config
Default value: Size related Parameter type: Option
Setup: 1 setup Conversion index: –
Data type: Uint8 Change during operation: True
Enable or disable the port mirroring function.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 209
