Dionex As - Assemblies, Tubing, and Fittings

AS Autosampler Operator’s Manual
128 Doc. 065051-03 1/08
5.1.2 Assemblies, Tubing, and Fittings
NOTE For other replacement parts (vials, well plates,
syringes, etc.), refer to Appendix F
.
Part Number Description Used For
057301 Needle seal assembly, 18-in, with
10-32 ferrule fitting
Connecting the AS inject port
to the injection valve
061290 Needle seal assembly, 18-in, without
10-32 ferrule fitting
Connecting the AS inject port
to two injection valves for
simultaneous injections
062564 Needle seal assembly, 24-in, with
10-32 ferrule fitting
Connecting the inject port of a
second AS to injection valve #2
in a dual-ICS-3000 system
054271 Sampling needle assembly, with a
1.2 mL volume
Connecting the sampling
needle arm to the sampling
valve, use with sample syringe
volumes of 1 mL or less
061267 Sampling needle assembly, with an
8.5 mL volume
Connecting the sampling
needle arm to the sampling
valve, use with sample syringe
volumes greater than 1 mL
044777
043276
043275
PEEK tubing: Green 0.75-mm
(0.030-in) ID
Double-cone ferrule fitting
10-32 double-cone bolt
Connecting the injection valve
port 6 (waste) to the AS drip
tray
042857 Sample loop, 25 μL Connecting ports 1 and 4 on the
injection valves (if installed)
049714 PEEK tubing: Blue, 0.33-mm
(0.013-in) ID
Connecting ports 1 and 2 on a
diverter valve to injection
valves (sequential injection
option only)
042855 PEEK tubing: Orange, 0.50-mm
(0.020-in) ID
Connecting the simultaneous
injection valve tee to each
injection valve
042690 PEEK tubing: Black, 0.25-mm
(0.010-in) ID
Sample loop
063405 PEEK tubing: Violet, 0.18-mm
(0.007-in) ID
Sample loop
