C.3 Detail Status Screen
Use the DETAIL STATUS screen to:
• Display detailed information about the status of AS operating parameters.
This screen displays all the information shown on the
MAIN STATUS screen,
plus additional parameters.
• Set several parameters for Direct Control operation.
NOTE See Section C.2 for descriptions of the parameters
common to the
MAIN STATUS and the DETAIL STATUS
screens.
Figure C-4. Detail Status Screen
Control Mode
SCH
(schedule) or
DIRECT
CONTROL
Press Select Δ or Select ∇ to select
SCH (schedule) or DIRECT
CONTROL mode. When the AS is in LOCKED RMT mode, Direct
Control is always selected.
In Schedule mode, the screen displays the number of the currently
running schedule, the schedule line, and the method. Enter the schedule
number to run (1 to 9) in the
SCH field.
Screen Field Description
Help prompt
INJECTING
VIAL#:
TIME:
INJ#:
VOL:
METHOD:
TRAY:
TRAY:
LOOP:
0.0
25
25
25.0
1
1/3
01 P10 mL
uL
uL
min
TTL1
TTL2
RLY1
RLY2
INJ VLV
0
1
0
0
L
NORMAL FULL
SCH 1
LOCAL
DETAIL
LINE 1
20 °C
