To run a test:
1. Move the cursor to the
ACTION field and select an action to perform.
For the
GO TO action, enter the desired XYZ positions.
2. Press
Enter.
C.9.4 Temperature Statistics Screen
Use the TEMPERATURE STATISTICS screen to:
• Manually control the temperature of the optional tray compartment
• Monitor the status of temperature-related values
NOTE This screen is available only when the temperature
control option is installed.
XYZ 1, 2, 3, 4
Allows entry of XYZ values for four needle arm positions. The
numbers indicate the number of motor steps away from the home
position.
X SENSOR
Y SENSOR
Indicates the current state of the X and Y sensors. The X and Y
sensors detect evenly spaced slots that indicate the home position
and mark distance intervals.
Z SENSOR
Indicates whether a vial is present. When the needle is down and a
vial is present, “1” is displayed. If no vial is present at the current
location when the needle is down, “0” is displayed.
Z HOME
Indicates whether the Z axis is at the home position. An entry of
“0” indicates home.
Figure C-29. Temperature Statistics Screen
Screen Field Description
Help Prompt
TEMPERATURE STATISTICS
TRAY SET TEMP:
MIN: MAX: TIME:0.1 A 12:34:5610.2
35
35.0
10.0
HEX
07
°C
A
A
123
*
ACTUAL:
PELTIER:
CONTROL:
DUTY CYC:
°C=
To Next Page
