AS Autosampler Operator’s Manual
272 Doc. 065051-03 1/08
C.9.9 Code Versions Screen
Displays revision numbers for the current digital signal processor (DSP)
code, syringe operating codes, moduleware, and USB BIOS code.
C.10 Time Function Out Screen
Use the TIME FUNCTION OUT screen to enable TTL control of an injection valve
installed in an ICS-1000, ICS-1500, ICS-2000, or ICS-3000.
Figure C-38. Code Versions Screen
Figure C-39. Time Function Out Screen
Screen Field Description Values
LOAD/INJECT
VALVE: TTL1,
TTL2
If the AS is not connected to Chromeleon or
Chromeleon Xpress, a TTL connection is required
between the AS TTL output and a TTL input on the
IC system. This will allow you to control the
injection valve in the IC system from the AS front
panel. See Appendix E
for TTL connection
instructions.
ENABLED/
DISABLED
(default=
TTL1
ENABLED)
Help Prompt
CODE VERSIONS
DSP REV
SAMPLE SYRINGE REV
PREP SYRINGE REV
n.nn
Xnnn
Xnnn
MODULEWARE REV
USB BIOS REV
n.nn
n.nn
Help Prompt
TIME FUNCTION OUT
TTL
1
2
LOAD/INJECT VALVE:
LOAD/INJECT VALVE:
ENABLED
DISABLED
STATE
