Doc. 065051-03 1/08 273
D • Front Panel Control
D.1 Accessing AS Screens
• Press the Menu button to display a menu of screens.
• To select a screen on the menu, press the numeric button corresponding to the
screen's number on the menu, or move the cursor to highlight the screen
number and press
Enter.
Example:
To go to the
SYSTEM PARAMETERS screen from the MAIN STATUS screen:
1. Press the
Menu button to display the MENU of SCREENS.
2. Press
5 to go to the MODULE SETUP MENU.
3. Press 5 again to go to the SYSTEM PARAMETERS screen.
To return to the
MAIN STATUS screen:
1. Press
Menu twice.
2. Press
Enter or 1.
D.2 Entering or Changing Values
NOTE You can enter or change screen field values only when
the AS is in Local mode (see Section 3.2
). To change
most fields, the AS must also be in Direct control.
1. Press a cursor arrow button to position the cursor in the field.
2. Enter the desired value, using the following buttons.
• To select from a list of predetermined options, press Select Δ or Select ∇;
repeat to scroll through the choices.
• To enter a numeric value, press the numeric buttons.
• To cancel an entry that is in progress and restore the previous value, press
Delete.
