AS Autosampler Operator’s Manual
58 Doc. 065051-03 1/08
3.5 Specifying Injection Volumes
The range of injection volumes the AS can deliver to the injection valve depends
on the size of the sample syringe installed on the AS and on the sampling mode
selected on the
SYSTEM PARAMETERS screen (see Section 3.6.2).
Table 3-3
lists the volume range for each syringe size and sampling mode.
You can enter the injection volume in the Chromeleon or Chromeleon Xpress
sequence (see Figure 3-10
and Figure 3-11) or in the front panel schedule (see
Section D.3
). For volumes less than 100 μL, specify the value in 0.1 μL
Syringe Size(s) Sampling Mode Injection Volume
100–1,000 μL Normal and Sequential 1.0–1,000 μL
Concentrate and
Sequential Concentrate
100–1,000 μL
5 mL Normal and Sequential 1.0–4,700 μL
Concentrate and
Sequential Concentrate
100–4,700 μL
Simultaneous 1,000–4,700 μL
10 mL Normal and Sequential 1.0–8,000 μL
Concentrate and
Sequential Concentrate
100–8,000 μL
Simultaneous 1,000–8,000 μL
Table 3-2. Summary of Injection Volume Ranges
