C • Display Screens
Doc. 065051-03 1/08 231
REMOTE
COMMAND IN
PROGRESS
The AS is performing a command while under
Chromeleon or Chromeleon Xpress control.
REMOTE
DIAGNOSTIC IN
PROGRESS
The AS is performing a diagnostic command
while under Chromeleon or Chromeleon Xpress
control.
REMOTE
CALIBRATION IN
PROGRESS
The AS is performing a calibration command
while under Chromeleon or Chromeleon Xpress
control.
VIAL#
The number of the vial the injection volume is taken from. The AS
updates the vial number after executing the
INIT step of the method’s
timed events.
INJ#
The number of injections completed using the current vial on the
current schedule line followed by the total number of injections
scheduled for this vial.
TRAY °C If the sample temperature control option is installed, this field displays
the current tray temperature. A symbol to the right of this field indicates
the temperature status (see below). If the sample temperature control
option is not installed, the field displays “--” and it is not illuminated.
= The temperature is stabilized
↑ The temperature is increasing
↓ The temperature is decreasing
-- The temperature control option is off
TIME
The number of minutes since the last injection. The clock counts up
until the next injection begins or until the maximum time of 999.9
minutes is reached.
VOL
The volume of sample to be injected.
Operating
Mode
LOCAL or
LOCKED
RMT (remote)
Select
LOCAL mode for control from the front panel. When the AS is
connected to Chromeleon or Chromeleon Xpress, connecting the AS to
a Control panel automatically selects
LOCKED RMT. In Locked
Remote mode, the front panel keypad is disabled to prevent any
changes to operating parameters. To return the AS to Local mode,
disconnect the AS from the Control panel, or turn off the AS power.
Note: The
REMOTE setting is not used.
Screen Field Description
