x DRUM Unit Installation Instructions
chap.5
264
t Push the ink pack to the set line on the ink pack.
y Push the side of the holder in with the palm of
your hand.
u Close the front cover.
"U" groove of holder
Set line
Set line
Front cover
q Invoke the HELP mode.
While holding down the Printing Speed
Adjustment keys "<" and ">" simultaneously,
turn the power on.
w Supply ink using HELP04.
Enter <0> <4> from the keypad and then press
the Print key.
Drum will begin to rotate while the ink pump
starts operation.After completion of supplying
ink, drum will stop rotating with continuous
beep sounds.
In general, it takes approx.30 seconds to supply
ink.
e Turn the power OFF and then ON again.
r Perform platemaking and printing of the
document.
: For more information, refer to
"Platemaking and printing proce-
dure" in the Instruction Manual.
The image will be light since ink is
not fully spread over the drum
surface. It is not a trouble. Con-
tinuously print approx.20 sheets.
IMPORTANT
t Once ink is fully spread, check the printed
image.If the density varies between the near and
far areas of paper, make adjustment according to
the "Adjusting Ink Amount".
(3)
Supplying Ink and Adjusting Ink Amount
1.Supplying Ink
