35
Mimic Zone 1
39
Mimic Zone 5
36
Mimic Zone 2
3
Mimic Zone 6
37
Mimic Zone 3
3
Mimic Zone 7
38
Mimic Zone 4
3
Mimic Zone 8
These output types will mimic the zone inputs. he output will operate when the
zone is unsealed and will reset when the zone is sealed. hey will operate regardless
of the zone type chosen (i.e. A zone "Not Used" can still operate a mimic output).
This feature operates when the system is armed or disarmed.
45
Global Chime
This output will operate when any zones programmed as "Chime" have triggered.
The output will reset when the zone has resealed. efer to Zone Types on page 162
for more information.
46
Zone Not Sealed
This output will operate whenever a burglary zone is unsealed. ime zones will
not operate this output event type.
47
Zone Not Sealed After Exit Time
This output will operate at the end of exit time if a burglary zone is unsealed. he
output will reset when all zones are sealed or the system has been disarmed. Chime
zones will not operate this output event type.
49
AC Mains 60 Hz Or 50 Hz
This output will activate when the AC mains supply frequency is at 60 Hz. The
output will reset once the AC mains supply has returned to 50 Hz.
198
Solution 862
Installation Manual
ISSUE130 Electronics Design and Manufacturing Pty Limited
