Soft-keys for adjustment and setup operations of the machine
In some configurations of the 1001DFB line, the optional graphic push-button “Operator” could be present,
it opens windows where the softkeys for setup and adjustment operations are displayed.
ATTENTION: the configuration of these soft-keys windows, number, disposition and meaning of
the graphic push buttons, is strictly complied to the 1001DFB configuration
bought. The followings “generals” pictures show all possible controls and can par-
tially correspond to the softkeys of the machine bought. The first one shows the
drilling unit soft-keys, whereas the second one the sawing unit soft-keys.
For special and/or customized soft-keys not shown in this manual, a special docu-
mentation will be supplied.
Soft-keys window for drilling unit
01
02
03
04
05
06
07
08
09
10
11
12
13
14
16
17
18
19
20
21
23
24
26
27
28
29
30
31
32
33
34
X
15
X
22
X
25
Only for machines with two drilling heads
