01: It enables the TEST mode to check a program
without any material: in TEST mode, the vices
of the drilling unit, the optional probes, the vices
of the sawing unit and the material hold-downs
are not qualified. The band guide movement,
the band descent and rotation remain qualified.
02: It enables the programmed stops (M01 function)
in the program in progress.
03: It enables the bar length pick-up automatic cy-
cle; the measurement is taken by two photo-
cells: the first one slows down the pincher for-
ward speed whereas the second one deter-
mines the bar length.
04: It enables the positioning of the drilling head to
the tool change prearranged quota. This is
available only for machines without automatic
tool changer.
05: It enables the roller vice type: this type of vice
can stay closed when the material slides.
06: It enables to use the optional vice extension: it
is required to process beams with minimum size
section.
07: It enables the “C axis extended minimum cycle“:
when selected, the drilling head can descent
until the minimum barrier.
08: It enables the use of the vertical clamping of the
vices in automatic mode.
09: It enables to use the vertical clamping extension
of the vices. The CNC takes into consideration
its dimensions to avoid collisions.
10: It enables the functioning test of the vertical
clamping in manual mode; the machine must be
in stand-by mode.
11: It enables the probing of profile width.
12: It enables the vertical probing of profile (height
of the web and flanges).
13: It stores the tool into the tool magazine in man-
ual mode.
14: It stores the tool into the tool magazine in man-
ual mode (second drilling head - optional).
15: Not used.
16: It enables the pincher automatic clamping of
material.
17: It prearranges the vertical coordinate of the
pincher in automatic mode. It is managed by the
CNC software.
18: It enables the pincher to catch the profile on
upper side instead on the lower side (only for
profiles with two horizontal parallel sides).
19: It enables the drilling sensitive cycle.
20: It inserts the tool into the spindle in manual
mode.
21: It inserts the tool into the spindle in manual
mode (second drilling head - optional).
22: Not used.
23: It enables the tool length pick-up by means of
the photocell in manual mode.
24: t enables the tool length pick-up by means of
the photocell in manual mode (second drilling
head - optional).
25: Not used.
26: It rotates the drilling head on side A of the pro-
file in manual mode.
27: It rotates the drilling head on side C of the pro-
file in manual mode.
28: It rotates the drilling head on side B of the pro-
file in manual mode.
29: It rotates the drilling head on side A of the pro-
file in manual mode (second drilling head -
optional).
30: It rotates the drilling head on side C of the pro-
file in manual mode (second drilling head -
optional).
31: It rotates the drilling head on side B of the pro-
file in manual mode (second drilling head -
optional).
32: It displays short textual descriptions under each
softkey by means of a safety password.
33: It displays the window of the sawing unit soft-
keys.
34: It escapes from soft-keys window and come
back to CNC execution page.
