Model 1001 DFB Programming and operating manual
FICEP S.p.A. 59
Programming: linear pattern of holes with same diameter
Meaning of the fields and possible choices
Pattern of holes with same diameter aligned on a same line
Selecting “LIN” in the “TYPE” field, a window is displayed to insert the parameters of the holes pattern
configuration and of the other field of the programming line.
Example: four holes with diameter 22 mm horizontally aligned, spaced 40 mm and executed on both
flanges with standard helicoidal tool
NOTE The values of X and Y coordinates are only as instances.
