Programming and operating manual Model 1001 DFB
72 FICEP S.p.A.
Choice of execution parameters (see next window of execution parameters)
Execution push-button for the nesting described in the zone n. 14
Push-button to delete a row in the zones n. 14 or 19
Push-button to save the all calculated bars into the bars list (see next window of bars
list)
Request for full automatic nesting; pressing this push-button the system doesn’t cal-
culate the number of requested bars for the present nesting and the bar quantity is
set to 9999; the CNC software determines the needed bars quantity calculating it in
real time as the bars are fed and automatically measured by the CNC
The push-button “Ordering” opens a window in which the operator can decide how to
sort the pieces to be nested (for instance increasing or decreasing order for length,
mark, contract, etc…)
Nesting request for the pieces selected in the zone n. 19
Possible request for pieces rotation; to be used for pieces with initial and/or final an-
gled cuts
Graphic warning for the scrap percentage; green colour: OK, red colour: too much
scrap. For the definition of the threshold limit see the section “Execution parameters”
on page 77
Basic procedure for nesting execution
Window for nesting operations; in the zone n. 19 the
list of pieces to be nested; if not, press “ESC” to
come back to programming general window and se-
lect the pieces to nest.
Choose your own setup of nest-
ing and execution
A window with execution parameters opens; the op-
erator must change the desired values. To finish the
operator must press the “F2” key of PC keyboard or
the graphic push-button “Confirm” on the screen. In
case of no modification the operator can press “ESC”
to close the window.
To know the meaning of each execution parameter
refer to next section “Execution parameters” on page
77.
Enter a value in field n. 11
This is the length of bars to use
Press “OK” (push-button n. 27)
The system ask for the authorization to nest pieces
with quantity different from zero
Press “OK” in the next window
to continue
The quantities “QTA” in the zone n. 19 decrease as
the pieces are nested in the zone n. 14.
N.B. In case of inconsistencies or programming er-
rors the nest is not executed and the line num-
ber of the selected piece in the zone n. 19 be-
comes red; the operator must remove the fault
and restart the nesting procedure.
Be sure that the nesting operation doesn’t need
a number of tools bigger than the line can use.
