FICEP 32292 - Procedure for semi-automatic cut

Programming and operating manual Model 1001 DFB
94 FICEP S.p.A.
The operator must inform the CNC about pincher orientation in the field “Carriage type” of the “Execution
parameters” window (see page n. 77).
Procedure for semi-automatic cut
It is possible to cut a bar without to program a nesting: the condition is that the profile in the setup table is
the same of the profile to be cut.
ATTENTION: if the profile to be cut is different from the profile in the setup table the CNC software
doesn’t know the true size of material and, thus, there is real danger of collision and blade
braking. In this case, before to carry out the cut, the operator must execute the initial setup
part of a program with the same profile.
If last processed profile, instead, is the same of which to be cut, all preliminary steps can be skipped and
the procedure can start directly from manual mode selection.
Control
Meaning
Remark
Start condition
Powered line, axes zero cycle executed, profile in setup
table different from the profile to be cut
“Programming”
Selection of general
programming window
Look through the list of pieces and select any program
with same profile of which to be cut. If there isn’t an al-
ready program, edit a new program with right profile.
“Execute”
Start of the program
By pressing the push-button “Execute” a window opens
with general information about the program to execute
“Execute”
Start of the program
The program starts
ESC
Coming back to the
general window
The canonic program has been generated
“Execution”
Selection of
execution window
Monitoring of the program to be executed
+
Automatic cycle start
(main push-button pan-
el)
The program is started in step by step mode
