Courier Text Col Row Default Setting Available Options

Description

Alarm Status 1 00 50

0=Unused

1=Unused

2=SG-optoInvalid

3=Prot'nDisabled

4=FoutofRange

5=VTFailAlarm

6=CTFailAlarm

7=CBFailAlarm

8=I^MaintAlarm

9=I^LockoutAlarm

10=CBOpsMaint

11=CBOpsLockout

12=CBOpTimeMaint

13=CBOpTimeLock

14=FaultFreqLock

15=CBStatusAlarm

16=ManCBTripFail

17=CBClsFail

18=ManCBUnhealthy

19=ManNoChecksync

20=ARLockout

21=ARCBUnhealthy

22=ARNoSysCheck

23=SystemSplit

24=UVBlock

25=SRUserAlarm1

26=SRUserAlarm2

27=SRUserAlarm3

28=SRUserAlarm4

29=SRUserAlarm5

30=SRUserAlarm6

31=SRUserAlarm7

This cell displays the status of the first set of 32 alarms as a binary string, including fixed and user settable alarms.

Chapter 4 - Configuration MiCOM P747

80 P747-TM-EN-1
