Courier Text Col Row Default Setting Available Options
Description
Active Group 00 0E 1, 2, 3, 4
This cell displays the active settings group
Software Ref. 1 00 11 <Software Ref. 1>
This cell displays the IED software version including the protocol and IED model.
Software Ref 2 00 12 <Software Ref. 2>
This cell displays the software version of the Ethernet card for models equipped with IEC 61850.
Plant Status2 00 25
This cell displays the circuit breaker plant status. The first two bits are used. One to indicate the 52A state and one to
indicate the 52B state.
Opto I/P Status 00 30
32 bit binary flag (data type G8):
0 = energised
1 = de-energised
This cell displays the status of the first set of available opto-inputs. This information is also available in the
COMMISSIONING TESTS column
Opto I/P Status2 00 31
32 bit binary flag (data type G8):
0 = energised
1 = de-energised
This cell displays the status of the second set of available opto-inputs. This information is also available in the
COMMISSIONING TESTS column
Relay O/P Status 00 40
32 bit binary flag (data type G9):
0 = operated state
1 = non-operated state
This cell displays the status of the available output relays.
MiCOM P747 Chapter 4 - Configuration
