Courier Text Col Row Default Setting Available Options
Description
Menu Cell Ref 01 02 (From Record) <Event type>
This cell indicates the type of event
Time & Date 01 03 (From Record) <Date and time of the event>
This cell shows the Time & Date of the event, given by the internal Real Time Clock.
Event Text 01 04 Not Settable
This cell shows the description of the event - up to 32 Characters over 2 lines.
Event Value 01 05 Not Settable
This cell displays a 32 bit binary Flag representing the event.
Select Fault 01 06 From to step
This setting selects the required fault record from those stored. A value of 0 corresponds to the latest fault and so on.
Faulted Phase 01 07 <Faulted phase>
This cell displays the faulted phase.
Start Elements1 01 08 <Start signal status>
This cell displays the status of the first set of 32 start signals.
Start Elements2 01 09 Not Settable
This cell displays the status of the second set of 32 start signals.
Start Elements3 01 0A Not Settable
This cell displays the status of the third set of 32 start signals.
Trip Elements1 01 10 Not Settable
This cell displays the status of the first set of 32 trip signals.
Trip Elements2 01 11 Not Settable
This cell displays the status of the second set of 32 trip signals.
Trip Elements3 01 12 Not Settable
This cell displays the status of the third set of 32 trip signals.
Fault Alarms 01 50 Not Settable
This cell displays the status of the fault alarm signals.
Fault Time 01 51 (From Record) Not Settable
This cell displays the time and date of the fault
Fault Type 01 52 Not Settable
This cell displays the fault type
Active Group 01 53 Not Settable
This cell displays the active settings group
System Frequency 01 54 Not Settable
This cell displays the system frequency
Fault Duration 01 55 Not Settable
This cell displays the duration of the fault time
CB Operate Time 01 56 Not Settable
This cell displays the CB operate time
Relay Trip Time 01 60 Not Settable
This cell displays the time from protection start to protection trip
Zone Test Mode 01 61 Not Settable
This cell displays the test mode to enter in commissioning mode by zone
MiCOM P747 Chapter 6 - Monitoring and Control
P747-TM-EN-1 159
