Courier Text Col Row Default Setting Available Options
Description
IX-1 to
IX-18 Magnitude
01
63 to
85
Not Settable
This cell displays the magnitude on analogue current channel 1 to 18
VxN Magnitude Z1
to Z4
01
A0 to
A3
Not Settable
This cell displays the magnitude on analogue voltage channel 1 to 4
Ix Z1 Diff 01 B0 Not Settable
This cell displays zone 1 differential current
Ix Z1 Bias 01 B1 Not Settable
This cell displays zone 1 bias current
Ix Z2 Diff 01 B2 Not Settable
This cell displays zone 2 differential current
Ix Z2 Bias 01 B3 Not Settable
This cell displays zone 2 bias current
Ix Z3 Diff 01 B4 Not Settable
This cell displays zone 3 differential current
Ix Z3 Bias 01 B5 Not Settable
This cell displays zone 3 bias current
Ix Z4 Diff 01 B6 Not Settable
This cell displays zone 4 differential current
Ix Z4 Bias 01 B7 Not Settable
This cell displays zone 4 bias current
Ix CZ Diff 01 B8 Not Settable
This cell displays check zone differential current
Ix CZ Bias 01 B9 Not Settable
This cell displays check zone bias current
Evt Iface Source 01 FA Not Settable
This cell displays the interface on which the event was logged
Evt Access Level 01 FB Not Settable
This cell displays the access level of the interface that initiated the event.
Evt Extra Info 01 FC Not Settable
This cell provides supporting information for the event and can vary between the different event types
Evt Unique Id 01 FE Not Settable
This cell displays the unique event ID associated with the event.
Reset Indication 01 FF No
This cell resets the trip LED indications if the relevant protection element has reset
Chapter 6 - Monitoring and Control MiCOM P747
160 P747-TM-EN-1
