APPENDIX A A.1 LOGIC OPERANDS
A
Input Status Board G (16 elements)
CONT IP_G_CC1 Input 1 (CC1) Board G
CONT IP_G_CC2 Input 2 (CC2) Board G
... ...
CONT IP_G_CC16 Input 16 (CC16) Board G
Output activation signals Board G (8 elements)
CONT OP OPER_G_01 Logic signal for Output 1 activation. Board G
CONT OP OPER_G_02 Logic signal for Output 2 activation. Board G
... ...
CONT OP OPER_G_8 Logic signal for Output 8 activation. Board G
Output Reset Signals Board G (8 elements)
CONT OP RESET_G_01 board G, 01 latched output reset
CONT OP RESET_G_02 board G, 02 latched output reset
... ...
CONT OP RESET_G_08 board G, 08 latched output reset
Contact Output Status Board G (8 elements)
CONT OP_G_01 Contact output 1 Board G operation
CONT OP_G_02 Contact output 2 Board G operation
... ...
CONT OP_G_08 Contact output 8 Board G operation
Board G Status BOARD G STATUS
Board G status: (0) Inactive - There is no
communication with the board (1) Active - There is
communication with the board
Input Status Board H (16 elements) - CIO MODULE
CONT IP_H_CC1 Input 1 (CC1) Board H
CONT IP_H_CC2 Input 2 (CC2) Board H
... ...
CONT IP_H_CC16 Input 16 (CC16) Board H
Output activation signals Board H (8 elements) - CIO
MODULE
CONT OP OPER_H_01 Logic signal for Output 1 activation. Board H
CONT OP OPER_H_02 Logic signal for Output 2 activation. Board H
... ...
CONT OP OPER_H_8 Logic signal for Output 8 activation. Board H
Output Reset Signals Board H (8 elements) - CIO
MODULE
CONT OP RESET_H_01 board H, 01 latched output reset
CONT OP RESET_H_02 board H, 02 latched output reset
... ...
CONT OP RESET_H_08 board H, 08 latched output reset
Contact Output Status Board H (8 elements) - CIO
MODULE
CONT OP_H_01 Contact output 1 Board H operation
CONT OP_H_02 Contact output 2 Board H operation
... ...
CONT OP_H_08 Contact output 8 Board H operation
Board H Status - CIO MODULE BOARD H STATUS
Board H status: (0) Inactive - There is no
communication with the board (1) Active - There is
communication with the board
Input Status Board H (16 elements) - CIO MODULE
CONT IP_J_CC1 Input 1 (CC1) Board J
CONT IP_J_CC2 Input 2 (CC2) Board J
... ...
CONT IP_J_CC16 Input 16 (CC16) Board J
Output activation signals Board J (8 elements) - CIO
MODULE
CONT OP OPER_J_01 Logic signal for Output 1 activation. Board J
CONT OP OPER_J_02 Logic signal for Output 2 activation. Board J
... ...
CONT OP OPER_J_8 Logic signal for Output 8 activation. Board J
Output Reset Signals Board J (8 elements) - CIO
MODULE
CONT OP RESET_J_01 board J, 01 latched output reset
CONT OP RESET_J_02 board J, 02 latched output reset
... ...
CONT OP RESET_J_08 board J, 08 latched output reset
