GE Multilin F650 Digital Bay Controller F-7
APPENDIX F F.1 FACTORY DEFAULT CONFIGURATION
F
SETPOINT > SYSTEM SETUP > BREAKER > BREAKER SETTINGS
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Number of Switchgear selected as
breaker
Number of Switchgear 1 1 [1 : 16]
Maximum value of KI2t Maximum KI2t 9999.99
0.01(KA)2
s
[0.00 : 9999.99]
KI2t integration time KI2t Integ. Time 0.03 0.01s [0.03 : 0.25]
Maximum number of openings Maximum Openings 9999 1 [0 : 9999]
Maximum Openings in one hour Max.Openings 1 hour 40 1 [1 : 60]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
SETPOINT > SYSTEM SETUP > BREAKER > BREAKER MAINTENANCE
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
KI2t Counter Phase A KI2t BKR Ph A Cnt 0.00
0.01 (KA)2
s
[0.00 : 9999.99]
KI2t Counter Phase B KI2t BKR Ph B Cnt 0.00
0.01 (KA)2
s
[0.00 : 9999.99]
KI2t Counter Phase C KI2t BKR Ph C Cnt 0.00
0.01 (KA)2
s
[0.00 : 9999.99]
Openings counter BKR Openings Cnt 0 1 [0 : 9999]
Closings counter BKR Closings Cnt 0 1 [0 : 9999]
SETPOINT > SYSTEM SETUP > SWITCHGEAR
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Snapshot Event generation for
switchgear #1
Snapshot Events
SWGR 1
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #2
Snapshot Events
SWGR 2
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #3
Snapshot Events
SWGR 3
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #4
Snapshot Events
SWGR 4
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #5
Snapshot Events
SWGR 5
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #6
Snapshot Events
SWGR 6
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #7
Snapshot Events
SWGR 7
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #8
Snapshot Events
SWGR 8
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #9
Snapshot Events
SWGR 9
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #10
Snapshot Events
SWGR 10
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #11
Snapshot Events
SWGR 11
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #12
Snapshot Events
SWGR 12
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #13
Snapshot Events
SWGR 13
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #14
Snapshot Events
SWGR 14
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #15
Snapshot Events
SWGR 15
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for
switchgear #16
Snapshot Events
SWGR 16
DISABLED N/A [DISABLED – ENABLED]
