11.4 Command Reference
────────────────────────────────────────────────────
■ Integrated measurement print/save item setting
Synta
x
INTEgrate:DATAout:ITEM data1,data2,data3
dat
a
data1, data2, data3 0 to 255 (numerical data in NR 1)
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
data1
Instantan-
eou
power
Instantan-
eou
current
Instantan-
eou
voltage
data2
Minimum
power
Minimum
current
Minimum
voltage
Maximum
power
Maximum
current
Maximum
voltage
data3
Power
integration
Average
value
Functio
n
･ Sets the save/print items for Integrated measurement mode. Send data
with the bits corresponding to the items to be output set to "1".
･ No error results if a bit with no corresponding item is set.
Erro
r
･ If the value other than setting limit is set, an execution error is generated.
･ In the following circumstances, a device dependent error generated:
If an attempt was made to execute this command while waiting for or
during integrated measurement.
In the event of a system error.
Exampl
e
Transmission
":INTE:DATA:ITEM 7,63,3"
Sets the Integrated measurement mode save/print items to "all data".
■ Integrated measurement print/save item query
Synta
x
INTEgrate:DATAout:ITEM?
Functio
n
Returns the items set for print/save in Integrated measurement mode in
(data1), (data2), or (data3) in the form of NR1 numeric data ranging from
0 to 255.
Respons
e
synta
x
If headers are ON
If headers are OFF
":INTEGRATE:DATAOUT:ITEM data1,data2,data3
"
"data1,data2,data3"
Exampl
e
If headers are ON
If headers are OFF
Transmission
Response
":INTE:DATA:ITEM?"
":INTEGRATE:DATAOUT:ITEM 7,0,0"
":INTE:DATA:ITEM?"
"7,0,0"
I
NTEgrate:DATAout:ITEM
I
NTEgrate:DATAout:ITEM?
