236
────────────────────────────────────────────────────
11.4 Command Reference
────────────────────────────────────────────────────
■ Wiring method setting
Synta
x
WIRing data
dat
a
1, 2, 3, 4, 5 (numerical data in NR1 format)
1: Single-phase, two-wire
2: Single-phase, three-wire
3: Three-phase, three-wire, two-current
4: Three-phase, three-wire, three-current
5: Three-phase, four-wire
Functio
n
Sets the wiring method.
Not
e
・If this setting is incorrect, correct measurements will not be obtained.
・If this command is executed, the current minimum/maximum value data is
reset.
Erro
r
･ An execution error results if any value other than that indicated above is
set for <data>.
･ If an attempt is made to execute this command while waiting for or during
integrated measurement, a device-dependent error results.
Exampl
e
Transmission
":WIR 1"
Sets the wiring method as single-phase, two-wire.
■ Wiring method setting query
Synta
x
WIRing?
Functio
n
Returns the wiring method setting as a numerical value in NR1 format.
Respons
e
synta
x
If headers are ON
If headers are OFF
":WIRING data"
"data"
Exampl
e
If headers are ON
If headers are OFF
Transmission
Response
":WIR?"
":WIRING 1"
":WIR?"
"1"
W
IRing
W
IRing?
