14.1 General
────────────────────────────────────────────────────
CAUTIO
･ The 3166 functions that utilize a floppy disk are designed specifically for the
9595 FDD UNIT. These functions will not work with any other floppy disk
drive unit.
･ The 9595 FDD UNIT should always be operated indoors in a range from 5℃
to 40℃ and 80% RH or less. Do not use the unit in direct sunlight, dusty
conditions, or in the presence of corrosive gases.
MS-DOS format
※
NEC PC9801
IBM-PC/AT
2HD 1.2MB 1.44MB
NOTE
4.1 General
The 9595 FDD UNIT is available as an option for the 3166 CLAMP ON
POWER HiTESTER . The features of this floppy disk drive are described
below.
(1) Can use 3.5-inch 2HD floppy disks (supports two modes)
* "MS-DOS" is a trademark of Microsoft Corporation.
(2) Saving and loading setting conditions
Measurements can always be taken under the same conditions by saving the
setting conditions and then loading them for future measurements.
(3) Saving measurement data
The floppy disk drive can be used to save measurement data.
The contents of the saved data file can be checked on the 3166 and then
output directly to the printer. In addition, because the data is saved in text
format on an MS-DOS format disk, the data can be analyzed, etc., on a
personal computer.
(4) Manual output and auto output
Data can be saved at any time by pressing the "Save" key. In addition, the
Auto Output function can be used in Integrated Measurement mode and in
Demand Measurement mode in order to automatically save measured values.
(5) The following operations can also be performed:"FD (floppy Disk)" mode
・Formatting floppy disks
・Changing file names
・Deleting files
・Updating (version upgrades)
Note that the saved setting conditions and each file operations are loaded in
"FD" mode.
