14.2 Type and Amount of Data That Can Be Saved
────────────────────────────────────────────────────
CAUTIO
In the case of demand measurement, the print/save item settings are made in
a special manner as described below.
1) First, set to "ON" all of the necessary items from among daily report, weekly
report, monthly report, demand measurement and integrated measurement.
(Multiple items may be set.)
2) Next, set the items that are to actually be output from among the
instantaneous values, maximum values, minimum values, integrated power
levels, and average values over time; these items are set in common with
the items selected in step 1 above. (Multiple items may be set.)
3) In short, only the items selected in both step 1 (tabulation period) and step 2
(output items) are selected and valid initially. If only one setting is set to
"ON", nothing is output.
NOTE
Format 1.2MB 1.44MB
Number of files 96 files 112 files
Format 1.2MB 1.44MB
Amount of data Approximately 23 days Approximately 28 days
Number of files 96 files 112 files
* Instantaneous value, maximum value, minimum value, integrated power
level and average value over time data from the period in question can all be
set in combination in the daily report, weekly report, monthly report, demand
measurement, and integrated measurement data (items 8 to 12 above). (The
data settings are common to all, however.)
●Setting conditions
All setting conditions can be saved from the "Setting screen" for each
measurement mode and in "Setting" mode.
(2) Amount of data and number of files that can be saved
How much data can be saved depends on the wiring method, the measurement
mode, and the setting items.
Specific examples are shown below. (Wiring in all cases is three-phase, four-
wire, including the setting files.)
The floppy disk, once full, can store no more data. Replace the floppy disk well
before it is full.
1. Normal Measurement mode, all items set to "ON".
2. Integrated Measurement mode, output interval of 30 minutes, all items set to
"ON".
