Measurement
Error
Error Display
ERR
No. 10 Pin
*
4
Comparator Measurement BIN Measurement
Logical
Product
AND
No. 14
Pin
Each Parameter
Judgment Result
Pin Nos. 11, 12, 13,
30, 31, and 32
BIN1 to BIN10, Pin
Nos. 11 to 15 and
30 to 34
OUT_OF_BINS
Pin No. 19
Sampling error LOW HI HI HI LOW
Overcurrent error LOW HI HI HI LOW
Simultaneous H and
L contact errors (after
measurement)
LOW HI LCR: 11, 31
*1
HI LOW
L side contact error
(after measurement)
LOW HI LCR: 11, 31
*1
HI LOW
H side contact error
(after measurement)
LOW HI LCR: 11, 31
*1
HI LOW
Simultaneous H and
L contact errors
(before measurement)
LOW HI LCR: 11, 31
*1
HI LOW
L side contact error
(before measurement)
LOW HI LCR: 11, 31
*1
HI LOW
H side contact error
(before measurement)
LOW HI LCR: 11, 31
*1
HI LOW
Underflow HI HI LCR: 12, 32
*1, 2
HI LOW
Overflow HI HI LCR: 11, 31
*1, 3
HI LOW
Outside of HIGH-Z
reject limit range
LOW
Normal
judgment
Normal
judgment
Normal
judgment
Normal
judgment
Outside of
guaranteed
accuracy range
HI
Normal
judgment
Normal
judgment
Normal
judgment
Normal
judgment
Normal
Measurement
Values
HI
Normal
judgment
Normal
judgment
Normal
judgment
Normal
judgment
No measurement
after power turned on
HI HI HI HI HI
*
1 Indicates the pin numbers that will be the LOW level.
*2 LCR 11 and 31 will be LOW when the parameters are Y, Cs, G, and B.
*3 LCR 12 and 32 will be LOW when the parameters are Y, Cs, G, and B.
*4 LOW will be output if even one error occurs.
