Hioki IM3533 - Setting the Measurement Parameter

6.1 About TRANSFORMER function
196
This section describes how to select Ls or Lp as the measurement parameter.
See "1.3.7 Parameter Settings Screen" (p. 28)
"Appendix1 Measurement Parameters and Calculation Formula"(p. A1)
"Appendix7 Series Equivalent Circuit Mode and Parallel Equivalent Circuit Mode"(p. A11)
6.1.3 Setting the measurement parameter
Procedure
Select a measurement parameter.
Parallel equivalent circuit mode induc-
tance (H)
Series equivalent circuit mode induc-
tance (H)
1
Touch the measurement parameter key on the
measurement screen.
2
TRANSFORMER Measurement Screen
Measurement Parameter Settings
3
Press to close the setting screen.
