13.1 Connecting the Printer
331
13
Chapter 13 Printing
Connecting the Printer
Recommended printer
The requirements for a printer to be connected to the instrument are as follows.
Confirm compatibility and make the appropriate settings on the printer before connecting it to the instrument.
See "13.2 Instrument and Printer Settings" (p. 333)
• Interface....................... RS-232C
• Characters per line....... At least 45
• Communication speed. 9,600 bps (Initial value)
• Data bits....................... 8bit (fixed)
• Parity............................ none (fixed)
• Stop bits ....................... 1bit (fixed)
• Flow control.................. none (Initial value)
Printing Chapter 13
Printing (p. 334)
• Measurement values and
comparator decisions
• Statistical calculation results
Connecting the printer
to the instrument
Make instrument
settings (p. 333)
Make printer
settings
13.1 Connecting the Printer
Because electric shock and instrument damage hazards are present, always follow
the steps below when connecting the printer.
• Always turn off the instrument and the printer before connecting.
• A serious hazard can occur if a wire becomes dislocated and contacts another con-
ductor during operation. Make certain connections are secure.
The printer can be connected only when the Z3001 RS-232C interface is connected.
The communication speed and flow control can be changed with instrument settings.
However, the instrument and printer must be configured with the same settings.
