Hioki IM3533 - Low Z High Accuracy Mode

4.2 Setting Basic Settings of Measurement Conditions
71
4
Chapter 4 LCR Function
In low Z high accuracy mode, an output resistance of 25  is used so that adequate current can flow to the
measurement sample, allowing highly accurate measurement.
2
Low Z High Accuracy Mode
Procedure
2
Press .
LCR Measurement Screen LCR Basic Settings
LCR Basic Settings
1
3
Range Setting
Select ON/OFF for the low Z high accuracy
mode.
Sets the low Z high accuracy mode to
OFF.
Sets the low Z high accuracy mode to ON.
4
Press to close the setting screen.
