10.1 Setting the Interface
263
10
Chapter 10 Setting the SYSTEM
You can control the instrument from a computer via the USB, GP-IB, RS-232C and LAN interfaces.
Printing can also be performed with RS-232C printer.
Setting the
SYSTEM Chapter 10
10.1 Setting the Interface
• The GP-IB, RS-232C, and LAN settings can only be configured when the optional Z3000 (GP-
IB), Z3001 (RS-232C), or Z3002 (LAN) is installed.
• Printer settings are only available when the Z3001 is installed.
1
LCR Measurement Screen
Interface Settings
Procedure
This operation is possible in any of the mode, mode and mode.
Normally, only USB set-
tings are available.
(Ref to Communication
Instruction Manual (LCR
Application Disk))
2
Select the interface type. (Only available when an optional interface is installed.)
See Printer Settings (p. 331)
For more information about settings other than the printer settings, see the Communication
Instruction Manual (LCR Application Disk).
GPIB Setting RS-232C Settings
LAN Setting Printer Setting (p. 331)
When Z3000 is installed
When Z3001 is installed
When Z3002 is installed
When Z3001 is installed
3
Press to close the setting screen.
To Next Page
