14.3 About Measurement Times and Measurement Speed
350
Measurement times differ depending on the measurement conditions. Refer to the following values.
• When the contact check function has been enabled, the following time will be added to INDEX depend-
ing on the contact check timing.
• Use of the BEFORE or BOTH contact check settings will result in longer analog measurement times
since the trigger synchronous output function's wait time is automatically allowed to elapse after the
contact check before measurement is started.
The above values are reference values based on use of the initial value for the wait time setting.
14.3 About Measurement Times and
Measurement Speed
All of the values are reference values. Note that they may differ depending on the condi-
tions of use.
Analog measurement signal (INDEX)
FAST MED SLOW SLOW2
DC (line frequency: 50 Hz) 43 ms 123 ms 203 ms 803 ms
DC (line frequency: 60 Hz) 37 ms 103 ms 203 ms 803 ms
0.001 Hz to 0.999 Hz Tf s + 3 ms Tf s + 3 ms Tf s + 3 ms Tf s + 3 ms
1.000 Hz to 10.000 Hz Tf s + 3 ms 2
× Tf s + 3 ms 3 × Tf s + 3 ms 4 × Tf s + 3 ms
10.001 Hz to 39.999 Hz Tf s + 3 ms 2 × Tf s + 3 ms 5 × Tf s + 3 ms 10 × Tf s + 3 ms
40.000 Hz to 99.999 Hz Tf s 2
× Tf s 5 × Tf s 40 × Tf s
100.00 Hz to 300.00 Hz Tf s 2 × Tf s 5 × Tf s 50 × Tf s
300.01 Hz to 500.00 Hz Tf s 2
× Tf s 10 × Tf s 200 × Tf s
500.01 Hz to 1.0000 kHz Tf s 5 × Tf s 20 × Tf s 300 × Tf s
1.0001 kHz to 2.0000 kHz 2
× Tf s 8 × Tf s 40 × Tf s 600 × Tf s
2.0001 kHz to 3.0000 kHz 4 × Tf s 12 × Tf s 60 × Tf s 1200 × Tf s
3.0001 kHz to 5.0000 kHz 6
× Tf s 20 × Tf s 100 × Tf s 2000 × Tf s
5.0001 kHz to 10.000 kHz 10 × Tf s 40 × Tf s 200 × Tf s 3000 × Tf s
10.001 kHz to 20.000 kHz 20
× Tf s 80 × Tf s 400 × Tf s 6000 × Tf s
20.001 kHz to 30.000 kHz 50 × Tf s 150 × Tf s 600 × Tf s 12000 × Tf s
30.001 kHz to 50.000 kHz 50
× Tf s 250 × Tf s 1000 × Tf s 20000 × Tf s
50.001 kHz to 100.00 kHz 100 × Tf s 400 × Tf s 2000 × Tf s 30000 × Tf s
100.01 kHz to 200.00 kHz 200
× Tf s 800 × Tf s 4000 × Tf s 60000 × Tf s
Tf[s]=1 ÷ measurement frequency[Hz]
Tolerance: ±5% ±0.2 ms
Contact check timing
BEFORE 2.5 ms
AFTER 1.0 ms
BOTH 3.0 ms
