11.5 Saving Instrument Settings
295
8
11
Chapter 11 Using USB Flash Drive
Save various setting information of the instrument including the panel save information as a setting file to the
USB flash drive.
The extension of the setting file is “.SET.” The extension of the panel save is “.PNL.”
For the settings that are saved, refer to "Appendix12 Initial Settings Table"(p. A18).
2 Saving All Settings of Instrument (ALL SAVE Function)
Procedure
2
LCR Measurement Screen File List Screen
Insert the USB flash drive into the USB port (front panel).
1
Press .
3
File List Screen
